guys just need someone to check my scaling factor for me please.
I using my old LEO1A 1/72 model as a reference. so 1 of its idler wheel measures ±Ø18.6mm. then I looked around for a "off the shelf" wheel close to Ø75mm. So then I divided 75/18.6=4.03225806451 and used this value to scale up all the measurements from the 1/72 plastic model. this makes it a ±1/18 scale. not to worried about accuracy here, its my first scratch built RC model.
now when I scale up the hull it looks a bit strange. it measures ±225mm x ±701mm! the original measures ±55.8mm x ±174mm (plastic model).
To me the hull seems LONGER than it is wide??
Have I missed something here or what??
thanks guys
|
|
|
|
|
31.12.2009, 19:20 Uhr
Marinus
|
Hi Captaintank sir,
I always use this Converter...
Perhaps it´s able for your Calculations too....
Greeting from "Good old Germany" and the best wishes for 2010
Marinus
--
groetjes,
Marinus
|
|
| Beitrag 1 mal editiert. Zuletzt editiert von Marinus am 31.12.2009 19:21.
|
|
|
02.01.2010, 16:35 Uhr
captaintank
|
quote:
Original von Marinus:
Hi Captaintank sir,
I always use this Converter...
Perhaps it´s able for your Calculations too....
Greeting from "Good old Germany" and the best wishes for 2010
Marinus
--
groetjes,
Marinus
thank you Marinus for the wishes and all the best for 2010 to u & family. r u coming to the world cup?
I get the same answer using that calculator, but it's not the maths I'm worried about, it's the proportion or ratio between the width & length of the hull.
225mm wide and 701mm long it just seems a bit out of proportion to me?
regards
CT
|
|
|
|
|
|
02.01.2010, 17:17 Uhr
Marinus
|
Hello Captaintank Sir,
Here are the measures from the "original"
the Hull length is 7090 mm... in Scale 1/18 393,88 mm
the Hull with is 3370 mm... in Scale 1/18 187,22 mm
or are you talking about the turrets hull ?
by the way... the Dutch are not just going to the Wold Championship... They are willing to win this in 2010
--
groetjes,
Marinus
|
|
|
|
|
|
02.01.2010, 18:41 Uhr
cknorr
|
Hello
I think your plastic Modell are in 1/35 scale 18,6mm x 35 =651mm.The idle Wheel you looked ist 75mm.
Original Wheel 1:1~651mm/75mm=8,68. Wenn you use the 75mm wheel your scale ist 1/8,68 not 1/18.
In Scale 1/18 you must use ~36,1666 mm idle wheel (651/18=36.16)
The faktor for your Modell is scale 35divided/scale 18 =1,9444.(18.6mmx1,9444=36,1666mm)
55,8x1,944=108mm
174x1,944=338mm
Grüße Christian
|
|
|
|
|
|
06.01.2010, 10:06 Uhr
captaintank
|
